A single-stage reverse osmosis system with a water production capacity of one ton per day
I.Product Description
A single-stage reverse osmosis (RO) system purifies water by forcing it through one semi-permeable membrane in a single pass, effectively removing contaminants like heavy metals, salts, bacteria, and dissolved solids for cleaner, better-tasting water, often used in under-sink or countertop units with pre/post-filters for enhanced filtration, though multi-stage systems offer deeper purification.
II.How It Works
Pre-Filtration: Tap water first passes through sediment and carbon filters to remove larger particles, chlorine, and chemicals that could harm the RO membrane.
Reverse Osmosis (RO) Membrane: Water is forced under pressure through the single, excellent RO membrane, which physically blocks most remaining impurities, contaminants, and dissolved solids.
Post-Filtration (Optional but Common): The water then typically goes through a final carbon filter (polishing filter) to enhance taste and odor before reaching the faucet or storage tank.
III.Technical Specifications
| Item |
Specification |
| Product Name |
Reverse Osmosis Water Treatment Plant |
| System Capacity |
250 LPH – 10,000 LPH |
| Feed Water Source |
Tap water / Groundwater / Surface water |
| RO Membrane Type |
Thin Film Composite (TFC) |
| Salt Rejection Rate |
≥ 98–99% |
| Recovery Rate |
50–75% (customizable) |
| Operating Pressure |
0.6 – 1.6 MPa |
| Feed Water TDS |
≤ 2000 ppm (higher TDS on request) |
| Product Water Quality |
TDS ≤ 10–50 ppm (depending on feed water) |
| Operating Temperature |
5 – 35 °C |
| Power Supply |
220V / 380V, 50Hz / 60Hz |
| Control System |
PLC / Manual Control (optional) |
| Frame Material |
SS304 / SS316 / Carbon Steel |
| Piping Material |
UPVC / SS |
| Pre-treatment |
Sand Filter + Carbon Filter + Softener (optional) |
| Installation |
Skid-mounted |
| Operation Mode |
Automatic / Semi-automatic |
FAQ
Q: Are you a trading company or a factory?
A: We are a factory.
Q: How Does Reverse Osmosis Work?
A: Reverse osmosis systems purify water by forcing pressurized water through a very fine Aromatic polyamide membrane. If the raw water being treated comes from a well or another private source, disinfection and pre-filters (to remove chlorine and/or particulates/sediment) may be needed in advance of the R/O unit to remove contaminants that can foul or damage the membrane.
Q: How Do I Know What Size Unit to Buy?
A: R/O units are rated according to the amount of treated water produced per day. For example, one type of unit produces 5000 liters of treated water per day under its design conditions. In reality, conditions frequently vary. Line pressure is often lower, water will frequently be colder than 25° C, and backpressure in the storage tank will likely reduce the performance of the unit. Consequently, you should examine water conditions and buy a larger-rated unit than needed if any of the above problems are noted
Q: Material of the reverse osmosis system?
A: You can choose FRP filter + U-PVC pipe, stainless steel filter + U-PVC pipe, or total stainless steel.
Q: What's your production Period?
A: Generally, for 50Hz voltage, we need 5 working days to finish; for 60Hz, we need 30 working days to finish.
Guidelines for getting a proper quotation:
1. Tell us the production capacity you want(500L/H,1T/H, 2T/H......)?
2. What is your source water(tap water/underground water....)?
3. What is the product water used for(drinking /bottled water....)?
4. If you have the water report, please send us.
